250 sheet paper cassette
| Pic No. | Parts ID | Parts Name | Link |
| 1 | CB500-67902 | Optional 250-sheet paper feeder - Includes cassette | Find 1 |
| 2 | RM1-4901-000CN | 250-sheet input paper cassette tray 3 | Find 2 |
Covers, panels, and doors
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RC2-3612-000CN | Power on/off button - Located on the front right cover | Find 1 |
| 2 | RC2-3606-000CN | Left side cover - For the Color LaserJet CP2025 printer series | Find 2 |
| 3 | RM1-4831-000CN | Upper cover assembly - For the Color LaserJet CP2025 printer series | Find 3 |
| 4 | RC2-3614-000CN | DIMM cover - Lift-up cover for memory DIMM access | Find 4 |
| 5 | RC2-3610-000CN | Right side panel assembly - For the Color LaserJet CP2025 printer series | Find 5 |
| 6 | RC2-3618-000CN | Right side cover assembly - For the Color LaserJet CP2025 printer series | Find 6 |
| 7 | RM1-4832-000CN | Control panel - Enables user interaction and communication with printer - For the Color LaserJet CP2025 printer series | Find 7 |
| 8 | RC2-3611-000CN | Front right side cover - For the Color LaserJet CP2025 printer series | Find 8 |
| 9 | RM1-4848-000CN | Front door assembly - Drop down door located on the front of the printer | Find 9 |
Fuser assembly
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RM1-6739-040CN | Fusing assembly - Bonds toner to paper with heat - For 220VAC to 240VAC (+/- 10%) operation | Find 1 |
| 1 | RM1-6739-220CN | Fusing assembly - Bonds toner to paper with heat - For 220VAC to 240VAC (+/- 10%) operation | Find 1 |
| 1 | RM1-6739-000CN | Fusing assembly - Bonds toner to paper with heat - For 220VAC to 240VAC (+/- 10%) operation | Find 1 |
| 1 | RM1-6738-000CN | Fusing assembly - Bonds toner to paper with heat - For 110VAC to 127VAC (+/- 10%) operation | Find 1 |
Internal Components 1
| Pic No. | Parts ID | Parts Name | Link |
| 2 | RM1-4836-000CN | Cartridge tray assembly | Find 2 |
Internal Components 2
| Pic No. | Parts ID | Parts Name | Link |
| 3 | RL1-1802-000CN | Multi-purpose/tray 1 paper pick-up roller | Find 3 |
| 4 | RM1-4850-000CN | Color misregistration sensor assembly | Find 4 |
| 5 | RM1-4852-000CN | Intermediate transfer belt (ITB) assembly | Find 5 |
Internal Components 3
| Pic No. | Parts ID | Parts Name | Link |
| 3 | RL1-1785-000CN | Multi-purpose/tray 1 separation pad | Find 3 |
| 4 | RM1-4839-000CN | Multi-purpose/tray 1 paper pick-up assembly | Find 4 |
| 5 | RM1-4426-000CN | Paper pickup roller (D-shaped roller) - Picks up media from the paper input tray | Find 5 |
| 6 | RM1-4840-000CN | Tray 2 separation roller assembly | Find 6 |
| 7 | RC2-2014-000CN | Cover holder - Located below the separation roller - For Color LaserJet series printers | Find 7 |
Internal Components 4
| Pic No. | Parts ID | Parts Name | Link |
| 3 | RK2-2302-000CN | Flat Flexible Cable (FFC) assembly - Connects between the DC controller board and the formatter board | Find 3 |
| 4 | RL1-1800-000CN | Drum Motor (M1) - Will work also as developing motor (M2) | Find 4 |
Internal Components 5
| Pic No. | Parts ID | Parts Name | Link |
| 3 | RK2-2276-000CN | Cooling fan (FM1) - Provides air to the right side of the printer | Find 3 |
| 4 | RM1-4873-000CN | Paper delivery assembly | Find 4 |
Internal Components 6
| Pic No. | Parts ID | Parts Name | Link |
| 3 | RC2-3604-000CN | Rear door assembly - For Color LaserJet printers | Find 3 |
| 4 | RC2-3605-000CN | Rear cover assembly - For the Color LaserJet CP2025 printer series | Find 4 |
| 5 | RC2-3598-000CN | Rear door stopper | Find 5 |
| 6 | RC2-3599-000CN | Cap link - For Color LaserJet printers | Find 6 |
| 7 | RM1-4838-000CN | Paper feed guide assembly - For simplex and duplex models - Includes the transfer roller | Find 7 |
Internal Components 7
| Pic No. | Parts ID | Parts Name | Link |
| 2 | RC2-3774-000CN | Link cap | Find 2 |
| 3 | RC2-3791-000CN | Upper rear cover - Color LaserJet CP2025 printer series (duplex models only) | Find 3 |
| 4 | RC2-3748-000CN | Lower rear cover - Color LaserJet CP2025 printer series (duplex models only) | Find 4 |
| 5 | RC2-3750-000CN | Rod link - Left and right side door rod link | Find 5 |
| 6 | RM1-4838-000CN | Paper feed guide assembly - For simplex and duplex models - Includes the transfer roller | Find 6 |
| 7 | RM1-4876-000CN | Rear door rib assembly - Includes fan (FM2) | Find 7 |
| 8 | RM1-4877-000CN | Paper pick-up guide assembly | Find 8 |
| 9 | RM1-4878-000CN | Rear door assembly | Find 9 |
| 10 | RM1-4879-000CN | Duplexing feed guide assembly | Find 10 |
| 11 | RM1-4880-000CN | Reverse drive assembly - For use with duplex models only | Find 11 |
PCAs
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RM1-5294-000CN | High voltage power supply PCA | Find 1 |
| 1 | RM1-5294-050CN | High voltage power supply PCA assembly | Find 1 |
| 2 | RM1-5303-000CN | High voltage power supply sub PCA | Find 2 |
| 3 | RM1-5431-000CN | DC controller PCA assembly | Find 3 |
| 3 | RM1-5431-060CN | DC controller PCA assembly | Find 3 |
| 4 | RM1-5293-000CN | Relay PC board assembly - For the Color LaserJet CP2025 printer series | Find 4 |
| 5 | RM1-5288-000CN | Driver PC board assembly - For the Color LaserJet CP2025 printer series | Find 5 |
| 6 | CB492-60002 | Formatter (Main logic) board - For the Color LaserJet CP2025 printer series | Find 6 |
Tray 2 assembly
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RM1-4860-000CN | 250-sheet input paper cassette tray 2 | Find 1 |
