Covers and external components
| Pic No. | Parts ID | Parts Name | Link |
| 7 | RM1-9953-000CN | Image scanner lock assembly | Find 7 |
| 8 | RC3-5015-000CN | Door, cartridge | Find 8 |
| 9 | RC3-4904-000CN | Stopper, paper (short media extension) | Find 9 |
| 10 | RL1-3874-000CN | Cover, rear | Find 10 |
| 1 | RM2-5127-000CN | Front cover assembly | Find 1 |
| 2 | RM1-9958-000CN | Paper pickup tray assembly | Find 2 |
| 3 | RM1-9905-000CN | Paper delivery tray assembly (output bin) | Find 3 |
| 4 | RL1-3872-000CN | Cover, top | Find 4 |
| 5 | RL2-0395-000CN | Cover, left | Find 5 |
| 6 | RC3-5011-000CN | Cover, right | Find 6 |
Document feeder assembly, fax models
| Pic No. | Parts ID | Parts Name | Link |
| 2 | CZ181-60107 | ADF core assembly | Find 2 |
| 3 | CZ181-60105 | ADF top cover assembly | Find 3 |
Document feeder core, fax models
| Pic No. | Parts ID | Parts Name | Link |
| 2 | CB780-60009 | Separator pad assembly (document feeder) | Find 2 |
Document feeder top cover, fax models
| Pic No. | Parts ID | Parts Name | Link |
| 5 | CB780-60032 | Pre-pick arm assembly | Find 5 |
| 6 | CZ181-60122 | Top cover with guide assembly | Find 6 |
Internal assemblies (1 of 3)
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RM2-5133-000CN | Fuser paper delivery assembly (110 V) | Find 1 |
| 1 | RM2-5134-000CN | Fuser paper delivery assembly (220 V) | Find 1 |
| 2 | RM2-7381-000CN | Engine control PCA (110 V) | Find 2 |
| 2 | RM2-7382-000CN | Engine control PCA (220 V) | Find 2 |
| 2 | RM2-7378-000CN | Engine control PCA (220 V) for China/India | Find 2 |
| 3 | RM1-9914-000CN | Fuser film assembly (110 V) | Find 3 |
| 3 | RM1-9915-000CN | Fuser film assembly (220 V) | Find 3 |
| 4 | RM2-7629-000CN | Delivery sensor PCA assembly | Find 4 |
Internal assemblies (2 of 3)
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RM2-5135-000CN | Pickup transfer frame assembly | Find 1 |
| 2 | RM1-4023-000CN | Roller, transfer | Find 2 |
| 3 | RM2-7384-000CN | Paper pickup sensor PCA assembly | Find 3 |
| 4 | RL1-2593-000CN | Roller, paper pickup | Find 4 |
| 5 | RM2-5131-000CN | Separation pad assembly | Find 5 |
Internal assemblies (3 of 3)
| Pic No. | Parts ID | Parts Name | Link |
| 1 | RM2-5126-000CN | Laser scanner assembly | Find 1 |
| 2 | RM2-7385-000CN | Motor PCA assembly | Find 2 |
| 3 | RM2-7377-000CN | Cable, flat (laser scanner) | Find 3 |
| 4 | RL2-0396-000CN | Motor, DC 24 V | Find 4 |
Scan drive system, all models
| Pic No. | Parts ID | Parts Name | Link |
| 7 | CN503-60006 | Scan motor encoder assembly | Find 7 |
| 13 | CZ181-60113 | Scanner with spring assembly | Find 13 |
Scanner and document feeder assembly, fax models
| Pic No. | Parts ID | Parts Name | Link |
| 1 | CZ181-60112 | Scanner assembly (fax models) | Find 1 |
| 2 | CZ181-60110 | Document feeder assembly | Find 2 |
| 3 | CZ181-60101 | Scanner and document feeder assembly | Find 3 |
Scanner assembly, base models
| Pic No. | Parts ID | Parts Name | Link |
| 3 | CZ186-60104 | SSA FFC Cable, 20 pin | Find 3 |
| 4 | CZ172-60103 | Scan bezel assembly (base models) | Find 4 |
| 6 | CZ181-60104 | Scan drive system assembly | Find 6 |
| 7 | CZ172-60104 | Scanner base assembly (base models) | Find 7 |
Scanner assembly, fax models
| Pic No. | Parts ID | Parts Name | Link |
| 2 | CZ186-60104 | SSA FFC Cable, 20-pin | Find 2 |
| 5 | CZ181-60102 | Scan bezel (fax models) | Find 5 |
| 7 | CZ181-60104 | Scan drive system assembly | Find 7 |
| 9 | CZ181-60103 | Scanner base assembly (fax models) | Find 9 |
Scanner lid, base models
| Pic No. | Parts ID | Parts Name | Link |
| 1 | CZ172-60107 | Scanner assembly (base models) | Find 1 |
| 2 | CZ172-60102 | Scanner lid (base models) | Find 2 |
| 3 | CZ172-60101 | Scanner lid assembly (base models) | Find 3 |
